EVERYTHING YOU NEEDNOTHING YOU NEED
Thoughtful engineering. Refined design.Made around the way you move.
MADE FORWHAT MATTERS
Optima brings the essential elements of a modern Teknix elevator into a refined and practical solution.
Designed for low-rise buildings, it combines gearless technology, thoughtful engineering and selected design options around the requirements of everyday movement.
A SMOOTHER WAY UP.
Every journey may only take a few seconds.
SMOOTH STARTS & STOPS
Controlled elevator movement for comfort at every floor.
PRECISE LEVELLING
Accurate floor alignment, every time.
GEARLESS PERFORMANCE
Efficient technology within a compact system footprint.
CONTROLLED DOOR OPERATION
Smooth and reliable operation across every cycle.
MAKE IT YOUR OWN.
Optima offers selected upgrade options to personalise the elevator around your project.
Options shown are representative. Final configuration subject to project requirements.
The essentials. Engineered with precision.
A refined gearless elevator solution designed around the requirements of modern low-rise buildings.
MRL / MMR
Machine Room-Less
408 – 884 KG
6 – 13 Persons
1 MPS
Metres per second
2 – 10
Floors
GEARLESS PMSM
Frequency Controlled
FULL COLLECTIVE
Selective
700 / 800 / 900 MM
Clear opening
2000 MM
Standard clear height
STANDARD CONFIGURATIONS
| PERSONS | LOAD | CAR WIDTH | CAR DEPTH | HOISTWAY WIDTH | HOISTWAY DEPTH | DOOR WIDTH | DOOR HEIGHT |
|---|---|---|---|---|---|---|---|
| 6 | 408 KG | 1160 mm | 960 mm | 1600 mm | 1500 mm | 700 mm | 2000 mm |
| 8 | 544 KG | 1300 mm | 1100 mm | 1800 mm | 1600 mm | 800 mm | 2000 mm |
| 10 | 680 KG | 1350 mm | 1300 mm | 1800 mm | 1900 mm | 800 mm | 2000 mm |
| 13 | 884 KG | 1400 mm | 1600 mm | 2100 mm | 2000 mm | 900 mm | 2000 mm |
| 15 | 1020 KG | 1000 mm | 2400 mm | 1800 mm | 3000 mm | 1000 mm | 2000 mm |
The specifications shown are standard reference configurations. Final dimensions and requirements may vary depending on the selected configuration and project requirements.
Intelligent control. Refined movement. Thoughtful protection
Multiple microcomputer-based close-loop control system with direct landing technology
Frequency-controlled permanent magnet synchronous motor-based gearless traction machine with dual vented disc brakes
Microcomputer senses the load in the elevator & generates the S curve based on the torque required automatically
VVVF door operating system with close-loop control
Full-length infrared light curtain provided for the safety of passengers
Stylish Integrated Car Operating Panel & Surface-mounted Landing Operating Panel with auto attendant key and auto light and fan function
Full Collective Selective
Car & Landing Operating Panels will be equipped with direction and floor indication display for easy facilitation of passengers
Wrong Destination call can be cancelled by double pressing the destination button
Ventilation & lighting would have an automatic on/off function
When the elevator speed is more than the calibrated speed, the device will automatically stop the elevator motor and activate the car safety device in turn activating the unintended car movement device to stop the car from moving further
Wrong Destination call can be cancelled by double pressing the destination button
