Hydratek brings advanced hydraulic technology, refinedengineering and Italian-inspired craftsmanship together.for an exceptionally smooth elevator experience.
Progressive Architecture with functionality & design at its core, Impressively and harmoniously combined in the interior that exudes sophisticated & precise German Engineering technology and advanced Italian workmanship that last for generations.
Hydratek comes with first in class ultra heavy duty guide rail drive system, with increased guide rail thickness for extra support and ultra smooth ride and longevity of the elevator
Teknix Hydratek elevators come with dynamic noise isolation technology using undercar dampers & floating upper car isolators for a noise & vibration free ride.
Teknix Hydratek elevators are pre-fitted with monomer-cast Polyamide sheaves which reduce the noise levels due to friction and thereby increasing the life of ropes by up to 50%.
Hydratek comes equipped with submerged drive system giving super smooth ride
Hydratek elevators are equipped with line rupture protection valves as a standard feature
HYDRATEK’S Progressive submerged fluid dynamics technology reduces the operating noise.
Teknix Hydratek is a new Generation vertical transportation system based on advanced progressive Fluid dynamics, researched and developed with the finest German Technology and Italian Craftmanship. Hydratek is born with state of the art critical components like new generation Ultra High Precision Submerged Drive for smooth fluid pressure with advanced Fluid control valves & stylish touch sensitive human interface devices together with technologically advanced components outperform to give you a impeccable elevator ride.
Pitless
Hydraulic Drive
Selective
1000 / 1200mm
| PERSONS | CAPACITY | CAR WIDTH | CAR DEPTH | HOISTWAY WIDTH | HOISTWAY DEPTH | DOOR WIDTH | DOOR HEIGHT |
|---|---|---|---|---|---|---|---|
| 6 | 408 kg | 1160 mm | 960 mm | 1600 mm | 1500 mm | 700 mm | 2000 mm |
| 8 | 544 kg | 1300 mm | 1100 mm | 1800 mm | 1600 mm | 800 mm | 2000 mm |
| 10 | 680 kg | 1350 mm | 1300 mm | 1800 mm | 1900 mm | 800 mm | 2000 mm |
| 13 | 884 kg | 1400 mm | 1600 mm | 2100 mm | 2000 mm | 900 mm | 2000 mm |
| 15 | 1020 kg | 1600 mm | 2400 mm | 1800 mm | 3000 mm | 1000 mm | 2000 mm |
The specifications shown are standard reference configurations. Final dimensions and requirements may vary depending on the selected configuration and project requirements.
Choose an interior design from our ready to pick preconfigured cars or make a choice and create your own concept from the range of materials available.
When on idle standby mode, elevator goes into hibernation function, where in the power consumption reduces by 80%, and starts up immediately on call registration.
Another outstanding feature of Hydratek is low Pit Depth Requirement and Zero Headroom space which adds extra space for you to use and giving you a clutter free headspace in the uppermost floor.
Hydratek elevators come with Multicomputer & machine learning based controller system, mated along with a Submerged Drive system & Direction control valve device for ultra smooth riding.
Hydratek uses high viscosity & high demulsibility fluid of biodegradable grade, and extreme long life making it much more environment friendly than other products.
Hydratek consumes 30-40% low power compared to other hydraulically operated elevators, due to the Progressive Submerged Drive system equipped with Mechanically or electronically operated Control valves giving high savings on power.
Multiple microcomputer based close-loop control system with direct landing technology
Frequency controlled permanent magnet synchronous motor based gearless traction machine with dual vented disc brakes
Microcomputer senses the load in the elevator & generates the S curve based on the torque required automatically
VVVF door operating system with close loop control
Full length infrared light curtain provided for safety of passengers
Stylish Integrated Car operating Panel & Surface mounted Landing Operating Panel with auto atiendant key and auto light and fan function
Full Collective Selective
Car & Landing Operating Panels will be equipped with direction and floor indication display for easy facilitation of passengers
Wrong Destination call can be cancelled by double press of destination button
Ventilation & lighting would have automatic on/off function
When elevator speed is more then the calibrated speed, the device will automatically stop the elevator motor and activate the car safety device in turn activating the unintended car movement device to stop the car from moving further
Automatic rescue mechanism that swiftly returns the elevator to the nearest floor during power outages.
